Green Self propelled 8m Hydraulic scissor lift with 450KG capacity for sale

Name: Green Self propelled 8m Hydraulic scissor lift with 450KG capacity for sale
Brand: JESH
Price: 1 USD

Wholesale Green Self propelled 8m Hydraulic scissor lift with 450KG capacity for sale from china suppliers

Brand Name : JESH

Model Number : SS0812HM

Certification : CE

Place of Origin : China

MOQ : 1Unit

Price : Negotiation

Payment Terms : T/T, L/C, D/P, D/A

Supply Ability : 4000 Units per month

Delivery Time : 45 days

Packaging Details : Regular factory packing

Color : Green

Working Height : 13.8m

Platform Height : 11.8m

width : 1.14m

Length : 2.48m

Capacity : 320KG

Platform extendable : 0.9m

Height-rails folde : 2.06m

Ground clearance-stowed : 10cm

Capacity on extension : 100kg

Turning radius(inside/outside) : 0/2.1m

Tire : 40.5*12,7m

Battery : 24V/260Ah

Hydrualic oil tank capacity : 25L

Weight : 2898kg

Contact Now

Important Features:

1)Slide out tray on left and right,easy for maintenance.

2)Forklift hole on the front for loading and discharging.

3)Unique pothole protection design.

4) Open type hydraulic system with anti-burst pipe protection
5) Emergency lower function assures platform operators can get down safely in case of emergency
6) Single lifting oil cylinder structure guarantees hydraulic pressure balance
7) Safety bar on the scissor part of the machine ensures operator safety during repair

Green Self propelled 8m Hydraulic scissor lift with 450KG capacity for sale

Specification Data:

Item	SS0812HM Self propelled scissor lift
Size	Metric
Max.Working Height	10.1m
Max.Platform Height	8.1m
Platform Length	2.27m
Platform Length-Extended	3.17m
Platform Extension	0.9m
Platform Width	1.14m
Height -Unfolded	2.35m
Height-folded	1.82m
Wheelbase	1.87m
Min. Ground Clearance-stowed	10cm
Min. Ground Clearance-Raised	2cm
Performance
Platform capacity	450kg
Extension platform capacity	120kg
Drive Speed	3.5km/h
Gradeability	25%
Raise/Lower Speed	32/42sec
Turning Radius(Inside/outside)	0/2.1m
Tire	40.5x12.7cm
Power	Electric power to drive the hydraulic motor
Battery	24V/260Ah
Hydraulic Oil Tank Capacity	25L
Machine Total Weight	2550kg
Engine	optional (perkins, Kohler,Deutz,Commins,Yanmar)

Warranty of scissor lifts:

1,5 years for the main structure,2 years for the whole machine . Engineers online support .

If purchase bulk orders our engineer can door to door service during the warranty period.

Shipping method:

6 units load into a 40' container,Jesh standard packing with plastic bag and wooden box .
